AUX Air Conditioner Service manual
50
Parts List
No. Part Name Quantity Remark
1 Panel assembly 1 Depend on the panel style of
individual model
2 Sterilization filter 2 Optional
3 Vitamin C anti-acrid filter 2 Optional
4 Filter 2
5 Screw cover 3
6 Cover of medium frame 1
7 Medium frame 1
8 Horizontal air blade 1
9 Vertical air blade 2
10 Air blade holder 1
11 Step motor 1
12 Through-flow fan 1
13 Rubber bearing holder 1
14 Plastic holder for left cruch
evaporator
1
15 Evaporator assembly 1
16 Chassis 1
17 Mounting plate assembly 1
18 Clamp of copper pipe 1
19 Indoot fan motor 1
20 Cover of indoor fan motor 1
21 Controller box 1
22 Transformer 1
23 Indoor sensor 1
24 Main PC board 1
25 Evaporator tube sensor 1
26 Remote receiver holder 1
27 Temperature control probe holder 1
28 Receiver board 1
29 Terminal board 1
30 Anion generator 1 Optional
32 Signal connection wire 1（2） 1 Correspondent with A. B
indoor unit
33 Power line 1
34 Indicator light seat 1 Depend on the panel style of
individual model
35 Display board 1 Depend on the panel style of
individual model
36 Remote controller 1 Sense function can be chosen
To Next Page
