AUX Air Conditioner Service manual
6
ASW-H09A+12A4/EA（L）2R1-II
Model No
Items
Indoor Unit A
(System A)
Indoor Unit B
(System B)
Outdoor Unit
Type Wall mounted model Heating pump
Cooling kw 3.2 2.5 /
Dehumidify kg/h 1.2 1.0 /
Heating kw 3.55 2.75 /
Noise level dB(A) 41 38 62
Cooling 2.6 2.6 /
Performance
EER
Heating
W/W
2.6 2.6 /
Power supply φ-V-Hz 1 / 220-240V~/ 50Hz
Cooling 1150 900 2010
Rated input
Heating
W
1220 980 2050
Cooling 5.0 3.91 8.74
Rated current
Heating
A
5.3 4.26 8.91
Length m 2 2 4.8
Supply cord
Class / 250V 10A 250V 10A 400V 25A
Starting Current A 30.5 21.7 /
Electrical Data
Fuse capacity A 3.15 3.15 3.15
Refrigerant/Charge g R410a/1100 R410a /950 /
Type / Rotary Rotary /
Model / PA140X2C-4FT
PA108X1C-4FZDE
/
Rated input W 1160/1200 885/915 /
Compressor
Overload
Protector
/ Inner B160-135-241E
MRA13430-9087
/
Heat exchanger Row*Hole 2*13 2*11 2*31
Type Capillary tube
Refrigerating System
Expansion device
Specification(mm)
φ3.0*900+φ3.0*1000
φ2.6*500+φ2.6*800
/
Air Volume m3/h 550 550 /
Cooling r/min 1180/1050/900/800 980/900/850/800 860 Fan Speed
H/M/L/Q
Heating r/min 1180/1050/900/850 980/900/850/850 860
Fan type / Cross flow Cross flow Propeller fan
Fan System
Fan motor output W 19 13 68
Connecting
Pipe
Gas /Liquid OD(mm)*L(mm) Φ9.52×5000/Φ6.35×5000
Connection
Drainage Pipe OD(mm)*L(mm) Φ14×780
Suitable area m2 12-21 12-17 /
Net dimensions
(W x H x D)
mm 745*250*210 745*250*210 331*846*901
Others
Net weight kg 10.5 9.5 70
