COM
2 x RS232 (Pin header)
Com1 of the RS232 above must have Pin 9 selectable by jumper (5V, 12V, RI) to
enable power to serial touch
Others
4 * USB 2.0 on 2 * 2mm 2 x 5 pin headers (same as ECM-CX700)
Rear I/O Connectors
USB
1 x USB3.0, 1 x USB 2.0
LAN
4 x Ethernet
HDMI
1 x HDMI
LED
Front Panel LED Connector (for system use)
Require same as ECM_CX700 LED indicators
-LED for Power
-LED for SATA access
Mechanical &
Environmental
Power Requirement
+12V power input (the same as ECM-CX700)
ACPI
Single power ATX Support S0,S3, S4, S5
ACPI 3.0 Compliant
Power Type
AT (4 x 1 header)
Operating Temp.
0°C ~ 60°C
Storage Temp.
And corresponding for above Operating Temp
Operating Humidity
0% ~ 90% relative humidity, non-condensing
Size (L x W)
4.5" x 6.5" (115mm x 165mm)
Weight
0.41 lbs (0.18 Kg)
Thermal
Two options. Option with active heatsink for current applications. Option with heat
spreader for embedding into future display
Heat spreader is required for processor on secondary side
Others
Mechanical mounting holes must match ECM-3610
Note: Specifications are subject to change without notice.
