2.3.15 EC Debug connector (JEC1)
Signal
PIN
EC_SMCLK_DEBUG
1
EC_SMDAT_DEBUG
2
GND
3
2.3.16 SATA power connector (SATAPW1)
Signal
PIN
GND
1
+5V
2
