ECM-BT45 User’s Manual
26 ECM-BT45 User’s Manual
2.3.17 Power connector (DC_IN1)
Signal
PIN
+12VSB
1
GND
2
GND
3
VIN_5V
4
2.3.18 LVDS connector (JLVDS1)
Signal
PIN
PIN
Signal
+12V
39
40
+12V
GND
37
38
GND
LVDS_CLK2_N
35
36
LVDS_CLK1_N
LVDS_CLK2_P
33
34
LVDS_CLK1_P
GND
31
32
GND
LVDS_DATA7_N
29
30
LVDS_DATA6_N
LVDS_DATA7_P
27
28
LVDS_DATA6_P
GND
25
26
GND
LVDS_DATA5_N
23
24
LVDS_DATA4_N
LVDS_DATA5_P
21
22
LVDS_DATA4_P
GND
19
20
GND
LVDS_DATA3_N
17
18
LVDS_DATA2_N
LVDS_DATA3_P
15
16
LVDS_DATA2_P
GND
13
14
GND
LVDS_DATA1_N
11
12
LVDS_DATA0_N
LVDS_DATA1_P
9
10
LVDS_DATA0_P
GND
7
8
GND
NC
5
6
NC
+3.3V
3
4
+5V
+3.3V
1
2
+5V
