ECM-BT45 User’s Manual
42 ECM-BT45 User’s Manual
3.6.2.8 IDE Configuration
Item
Options
Description
Serial-ATA (SATA)
Enabled[Default]
Disabled,
Enable/Disable Serial ATA.
SATA Speed Support
Gen1
Gen2[Default]
SATA Speed Support Gen1 or Gen2.
SATA ODD Port
Port0 ODD
Port1 ODD
No ODD[Default]
SATA ODD is Port0 or Port1.
SATA Mode
IDE Mode
AHCI Mode[Default]
Select IDE/AHCI.
Serial-ATA Port 0/1
Enabled[Default]
Disabled,
Enable/Disable Serial ATA Port0/1.
