1.5 System Specifications
System
CPU
Intel® Atom™ Processor E3845 (on bottom side of board)
BIOS
AMI uEFI BIOS, 64Mbit SPI Flash ROM
System Chipset
Valleyview SoC integrated
I/O Chip
EC(IT8528)
System Memory
1 x 204-pin DDR3L 1066/1333 SODIMM up to 8G
Watchdog Timer
H/W Reset, 1sec. – 65535sec./min.
1sec. or 1min. step
H/W Status
Monitor
CPU & system temperature monitoring
Voltages monitoring
Expansion
1 x mini-PCIe
PC/104 (Just ISA)-via Fintek chip F85226AF ( interfaced to LPC bus )
I/O
MIO
1 x SATA II (with SATA power connector required) Must be able to boot CF using
CF-> SATA adaptor
USB
1 x USB3.0, 5 x USB 2.0
Display
Chipset
Valleyview SoC integrated Graphics
Resolution
HDMI mode:1920 x 1080@60Hz, + 1024 x 768 + 640 x 480
LVDS 1920 x 1080@60Hz + 1024 x 768 + 640 x 480
Multiple Display
HDMI ＋ LVDS
HDMI
HDMI x 1
LCD Interface
Dual channel 18/24-bit LVDS
LVDS connector the same as ECM-CX700
Audio
Audio Amp
Standard BIOS Sonalert beeper required
Ethernet
LAN Chip
4 x Intel I211AT controller
Ethernet Interface
10/100/1000 Base-Tx compatible
Internal I/O
Connectors
Fan
Fan x1 (4 PIN PWM FAN)
Buzzer
BIOS alert beeper is required
CMOS Battery
CR2032
