ECM-BT45 User’s Manual
ECM-BT45 User’s Manual 17
HDMI1
HDMI connector
JCOM1
Serial port 1 connector
5 x 2 header, pitch 2.00mm
JCOM2
Serial port 2 connector
5 x 2 header, pitch 2.00mm
JBKL1
LCD inverter connector
5 x 1 wafer, pitch 2.00mm
Matching Connector: JST PHR-5
JFP1
Miscellaneous setting connector
5 x 2 header, pitch 2.00mm
JLPC1
Low pin count connector
5 x 2 header, pitch 2.00mm
JLVDS1
LVDS connector
20 x 2 wafer, pitch 1.25mm
Matching Connector: Hirose
DF13-40DS-1.25C
USB1
On-board connector for USB3.0
USB2
On-board connector for USB2.0
JUSB1
On-board header for USB2.0
5 x 2 header, pitch 2.00mm
JUSB2
On-board header for USB2.0
5 x 2 header, pitch 2.00mm
JEC1
EC Debug connector
3 x 1 header, pitch 2.00mm
LAN1
RJ-45 Ethernet connector
LED1
LED connector
DC_IN1
Power connector
4 x 1 wafer, pitch 5.80mm
SATAPW1
SATA power connector
2 x 1 wafer, pitch 2.00mm
SATA1
Serial ATA connector 1
PC1#1
PC connector 1
32 x 2 wafer, pitch 2.54mm
PC1#2
PC connector 2
20 x 2 wafer, pitch 2.54mm
JSPI1
SPI connector
4 x 2 header, pitch 2.00mm
MPCIE1
Mini-PCI connector
SO_DIMM1
DDR3L SODIMM connector
