Fine adjustment of the anti-roll device:
• The fine adjustment of the anti-roll device is
carried out via the knurled screw (fig. 23.6).
Selecting the clearance angle:
• Loosen the clamping lever (fig. 23.8) on the
left side of the knife carrier.
• Swivel the upper part of the knife
carrier on the base until the desired
clearance angle is reached.
• The clearance angle can be read
on the scale (fig. 23.9) on the left side on
the base.
• Bring the clamping lever (fig. 23.8) upwards
into clamping position.
• The selected clearance angle is now fixed
in its position.
Note:
Usable cuts are only achieved at a clearance
angle of 10° or more!
