2-7-2 DISPOSABLE BLADE CARRIER EC
The disposable blade carrier takes up all commercially available low profile blades with a dimension of
80 x 8 mm and a facette angle of approx. 35° and as another version it takes also up high profile
blades. The anti-roll plates have a length of 39,5 mm.
Fig. 24
1
2
3
4
5
6
7
8
10
9
11
