3 — Operation
3 - 36 Service Instructions RP-A301CE/RP-A351CE/RP-A355CE
Blade cleaning
1. Press a damp cloth on the front side
of the blade and move slowly from
the center towards the edge in the
direction of the arrow.
2. Rotate the slice deflector and keep it
away from the blade.
3. Follow these instructions to clean the
back side of the blade.
4. With a cloth dry both sides of the
blade following this procedure.
5. Insert a damp cloth between the
blade and the protection ring. Pull it
outwards and rotate it to clean the
internal side of the protection ring.
IMPORTANT:
Leave all the parts to soak in warm water
and washing-up liquid (do not use strong
detergents) and clean them by using a
brush or a cloth. Rinse them in warm water
and dry them.
To assemble the machine carry out the
reverse of the disassembly procedure.
5. After cleaning reposition the blade
cover, insert the fastener and screw
in a clockwise direction to clamp the
blade cover. Lower the sharpener
protective cover.
