Chapter 2: Installation 11
To cascade multiple AutoView switches if your switch does not have an ACI port:
1. Connect an AVRIQ-PS/2 module to the local peripheral ports on the cascaded switch.
2. Using an appropriate length of CAT 5 cable, connect the AVRIQ-PS/2 module from step 1 to
an available port on your 3008/3016 switch.
3. Repeat steps 1 and 2 for all additional cascaded AutoView switches.
NOTE: The system will automatically “merge” the two switches together as one. All servers connected to the
cascaded AutoView switch will display on the main AutoView switch server list in the OSCAR interface.
