Chapter 3: Local Port Operation 25
Figure 3.11: OSCAR Interface Name Modify Dialog Box
2. Type a name in the New Name box. Names of target devices may contain all
printable
characters.
3. Click OK to assign the new name.
4. Repeat steps 1-3 for each target device in the system.
5. Click OK in the Names dialog box to save your changes.
-or-
Click X or press Escape to exit the dialog box without saving changes.
NOTE: Changes made in the Names Modify dialog box are not saved to the switch until you click OK in the
Names dialog box.
NOTE: If an IQ module has not been assigned a name, the EID is used as the default name.
Commands Dialog Box Functions
From the OSCAR interface Commands dialog box, you can manage your AutoView 3008/3016
switching system and user connections, enable the Scan mode and update your firmware.
Table 3.6: Commands to Manage Routine Tasks for Your Target Devices
Features Purpose
Scan Enable Begin scanning your target devices. Set up a target device list for scanning in the Setup
dialog box. You must have at least two target devices selected in the Setup - Scan List
menu to enable target scanning.
User Status View and disconnect users.
AVRIQ Status Displays the currently available firmware for each type of AVRIQ module.
