Avocent DSR2020 User Manual

Chapter 1: Product Overview 3
Figure 1.1: Example DSR Switch Configuration
Figure 1.2: DSR Switch Model Comparison
Digital User
(Computer with Internet browser)
Analog User
(OSCAR Graphical
User Interface)
DSR Switch
Modem
Telephone
Network
Ethernet
DSView 3
Software
Server
Model
Number
of
Servers
Digital
paths
Analog
User
DSR1020 16 1 1
DSR2020 16 2 1
DSR4020 16 4 1
DSR8020 16 8 1
DSR Switch

Avocent DSR2020 Specifications

General

Brand	Avocent
Model	DSR2020
Category	Switch
Language	English
