Chapter 3: Local Port Operation 27
4. Click the Broadcast Enable checkbox to activate Broadcasting.
5. From the user station, type the information and/or perform the mouse movements you wish
to broadcast.
To turn Broadcasting off:
From the Commands dialog box, clear the Broadcast Enable checkbox.
Using Scan mode
In Scan mode, the DSR switch automatically scans from port to port (target device to target
device). You can scan up to eight target devices, specifying which ones to scan and the number of
seconds that each will display. The scanning order is determined by placement of the target device
in the list. The list is always shown in scanning order. You can, however, choose to display the
target device’s name or EID number by pressing the appropriate button.
NOTE: Scanning is only available to the local user.
To add target devices to the Scan list:
1. If the OSCAR interface is not open, press
Print Screen. The Main dialog box will appear.
2. Click Setup - Scan. The Scan dialog box appears.
Figure 3.11: Scan Dialog Box
