Appendices 79
Appendix F: Technical Specifications
Table F.1: DSR Switch Product Specifications
Server Ports
Number 16 (DSR1020/2020/4020/8020 switches)
Types
DSRIQ-PS/2, DSRIQ-USB, DSRIQ-VSN (Sun VGA), DSRIQ-WSN (Sun
13W3) and DSRIQ-SRL modules
Connectors RJ-45
Sync Types Separate horizontal and vertical
Plug and Play DDC2B
Video Resolution
640 x 480 @ 60 Hz (Local Port and Remote Port Minimum)
800 x 600 @ 75 Hz
960 x 700 @ 75 Hz
1024 x 768 @ 75 Hz
1280 x 1024 @ 75 Hz (Remote Port Maximum using a DSRIQ module)
Supported Cabling 4-pair UTP CAT 5 or CAT 6, 10 meters maximum length
SETUP Port
Number 1
Type Serial RS-232 Null Modem Cable
Connector DB9 Male
Network Connection
Number 1
Type Ethernet: IEEE 802.3 2002 Edition - 10BaseT, 100BaseT, 1000BaseT
Connector RJ-45
Local Port
Number 1
Type PS/2 and VGA
Connectors PS/2 MiniDIN and 15-pin D-Sub
MODEM Port
Number 1
Type Serial RS-232
Connectors DB9 Male
