30 DSR Switch Installer/User Guide
Setting local port Screen Saver options
Use the Screen Saver dialog box to manage the screen saver inactivity time and test the Screen
Saver mode on the local port. If security has been enabled in the DSView software, after the
specified Inactivity Time elapses, the local port locks and remains locked until you press any key or
move the mouse. You will then need to log in to continue.
To access the OSCAR interface Screen Saver dialog box:
1. If the OSCAR interface is not open, press
Print Screen. The Main dialog box will appear.
2. Click Setup - Screen Saver. The Screen Saver dialog box appears.
Figure 3.13: Screen Saver Dialog Box
To set the Screen Saver options:
NOTE: The Screen Saver password is set within the DSView software. For more information, see the DSView
Installer/User Guide.
1. Type the number of minutes for Inactivity Time (from 1-99) to delay activation of password
protection and the screen saver feature.
2. For Mode, select Energy if your monitor is E
NERGY STAR
®
compliant; otherwise
select Screen.
CAUTION: Monitor damage can result from the use of Energy mode with monitors not compliant with
ENERGY STAR
®
.
