PAGE 113
Interfaces
TAB. 14 PIN ASSIGNMENT: CLOCK INPUT (CLK IN)
Socket: XLR
Pin Signal Electrical characteristics
1 Analogue GND TTL
2CLOCK IN
3not used
TAB. 15 PIN ASSIGNMENT: CLOCK OUTPUT (CLK OUT)
Connector: XLR
Pin Signal Electrical characteristics
1 Analogue GND TTL
2CLOCK OUT
3not used
Push
12
3
2
1
3
