AVT MAGIC TH2 - A5.2 LCD Display; A5.3 Power Supply

PAGE 119
Technical Data
Connection to keypad (3):
8-pol. MINI DIN connector
Assignment:
Pin 2: clock
Pin 3: +5V
Pin 4: Data
Pin 5: GND (Ground)
A5.2 LCD Display
2 x 20 characters
illuminated
A5.3 Power supply:
5V, max. 500 mA
Connection:
6-pol. Mini-DIN socket
Assignment:
Pin 3: GND (Ground)
Pin 4: +5V
2
3
1
6
4
5
