Interfaces
A3.4 Power supply interface
The power supply is connected via an external power supply adapter.
TAB. 16 PIN ASSIGNMENT: POWER SUPPLY
Socket: KYCO KPJ-S3
Pin Signal Electrical characteristics
1 GND Voltage: +12V
Power: max. 15W
2+12V
3not used
1
3
2
