32
Auto Tracking
Set the surveillance area for auto tracking, and the tracking timeout.
When the locked target is out of the pre-defined surveillance area or stops moving for a pre-defined
period of time, the camera returns to the point it originally monitors.
Item Description
Limit 1 When the locked target moves out of the surveillance area, the camera returns to the point it
originally monitors after the preset tracking timeout.
By clicking and dragging the slider, set the left end of the surveillance area from 0º ~ 360º.
Limit 2 When the locked target moves out of the surveillance area, the camera returns to the point it
originally monitors after the preset tracking timeout.
By clicking and dragging the slider, set the right end of the surveillance area from 0º ~ 360º.
Time When the locked target stops moving longer than the pre-defined tracking timeout, the camera
returns to the point it originally monitors after the preset tracking timeout.
By clicking and dragging the slider, set pre-defined tracking timeout of the camera from 5 ~ 60
seconds, or you can choose to have no time limit (Infinite).
Video
Adjust video-related settings in different video format.
“Quality” is related to image clearness.
“FPS” is related to the fluency of the video. The more the FPS, the more fluent the video.
“Max Bit Rate” is the maximum limitation of data transmission in the selected image format and resolution.
To Next Page
