Avtech DG1015 User Manual

MAIN MENU
39
4) RATE
Select the baud rate for the connected PTZ camera (2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200).
Make sure the baud rate setting of the camera is the same as the setting here, or the DVR will not be able to
control the device.
Note: To know the default baud rate of the PTZ camera, please refer to its user manual.
6.4.8 DCCS
This function is used for our brand’s HD CCTV camera series. Users could access the setup menu of the camera
itself for further configurations.
ADVANCED CONFIG
C A M E R A CH1 CH2 CH3
CH4
DETECTION DIAGNOSTIC START
ALERT MENU SETUP
NETWORK
DISPLAY
RECORD
DEVICES
DCCS
IVS DEVICE CAMERA
NOTIFY CONNECTION UNKNOWN
EXIT
1) DIAGNOSTIC
When our brand’s HD CCTV camera is connected, click “START” to ensure the DVR recognizes it. This
function disappears when the DVR recognizes the camera properly.
2) MENU
Click “SETUP” to enter the camera’s configuration page.
6.4.9 IVS
Note: This function is for selected models only.
Note: Before using the IVS function, make sure the event record function is enabled on your DVR.
IVS, Intelligent Video Surveillance, is the advanced application for motion detection, but more precise and smarter.
It can be applied to different situations with one of the following three modes: FLOW COUNTING, VIRTUAL
FENCE, and ONE WAY.
When anyone crosses the detection line (virtual fence), the recording will be on.
Note: Four camera channels are supported for this function.
ADVANCED CONFIG
C A M E R A IVS1 IVS2 IVS3
IVS4
DETECTION CAMERA CH3 
ALERT IVS MODE FLOW COUNTING 
NETWORK DISPLAY LINE OFF 
DISPLAY SENSITIVITY 7
RECORD RESET COUNT SUBMIT
DEVICES VIRTUAL FENCE AREA SETUP
DCCS SCENE CHANGE OFF 
IVS SCENE CHANGE LEVEL MIDDLE 
NOTIFY
EXIT
1) CAMERA
Select the camera channel that you want to use the IVS function.
