APPENDIX 2 PUSH VIDEO CONFIGURATION
61
APPENDIX 2 PUSH VIDEO CONFIGURATION
Note: This function is for selected models only.
A2.1 Alarm Sensor Connection
Connect the alarm sensor, such as magnetic contacts, to the alarm-in port on the DVR rear panel. Alarm-in 1
corresponds to video channel 1, alarm-in 2 corresponds to video channel 2, and so on.
Note: The voltage restriction for alarm-in device connection is under DC24V 1A.
