3.4.7 Profibus-DP driver errors
An active error of the Profibus-DP driver is signalled by the ERR-PB red led. To know the error
code, read the parameter 2032h:
Property
Value
Parameter
2032h
Logic View menu
All parameters/System/Profibus-DP
Data type
16 bit int
Measurement unit
--
Value
0 = no errors
1 = VPC3 failure
2 = VPC3 initialization error
4 = VPC3 system error
5 = VPC3 system error
6 = VPC3 system error
7 = VPC3 system error
9 = VPC3 system error
10 = VPC3 system error
11 = VPC3 system error
15 = parameter setup request error
16 = invalid length of configuration telegram
17 = bad configuration
19 = watch dog
20 = size of data to be exchanged too large
21 = invalid station address
Access
Read-only
