10 PC TOOLS
10.1 GENERAL DESCRIPTION
The setup program installs the PC tools for configuring the module (Logic View) and upgrading the
firmware version (CANDPSX Firmware Upgrade). Both software tools use the COM port. SoftTune
supports the Modbus protocol, whereas CANDPSX Firmware Upgrade implements a dedicated
protocol.
10.2 THE CONFIGURATION TOOL
10.2.1 Overview
List of the parameters
of the selected menu
Parameters
menu
Parameter monitor
window supporting
drag & drop
Toolbar for data
exchange
Record of
the selected
parameter
Connection to
the module
