3 SYSTEM SETTINGS
3.1 INTRODUCTORY REMARKS
All the functions of CANDPSX can be configured, therefore this module implements an internal
database with a set of parameters for setting the operating characteristics.
Any changes to configuration parameters are actually applied only when the module is switched on
again or reset after the settings have been saved to non-volatile memory (see § 30).
3.2 OPERATING MODE
CANDPSX supports three operating modes for real-time data exchange between a Profibus-DP
and a CAN bus network.
3.2.1 Operating mode selection
To select an operating mode, set the parameter 2011h:
Property
Value
Parameter
2011h
Logic View menu
All parameters/System
Data type
8 bit unsigned int
Measurement unit
--
Value
0 = Profibus-DP slave / CAN
1 = Profibus-DP slave / CANopen Master
2 = Profibus-DP slave / CANopen Slave
Default value
0
Access
Read/Write
3.3 CAN COMMUNICATION
To specify the baud rate of the CAN line, set the parameter 2040h:
Property
Value
Parameter
2040h
Logic View menu
All parameters/System/CAN
Data type
8 bit unsigned int
Measurement unit
--
Value
0 = 1000 Kbits/s;
2 = 500 Kbits/s;
3 = 250 Kbits/s;
4 = 125 Kbits/s;
5 = 100 Kbits/s;
8 = 50 Kbits/s;
Default value
4
Access
Read/Write
