CANDPSX user manual rev 2 Page 30 of 42
____________________ _
7 SAVING AND VALIDATING A CONFIGURATION
7.1 INTRODUCTION
To apply any changes to configuration parameters of the CANDPSX module, you will have to give
a save-parameters command followed by a power-on or a software reset command.
7.2 SAVING THE SETTINGS
To save the current configuration, set the parameter 2000h:
Property
Value
Parameter
2000h
Logic View toolbar
Data type
8 bit unsigned int
Measurement unit
--
Value
1 = save command
Default value
0
Access
Read/Write
To give a software reset command (instead of a power-on), set the parameter 2002h:
Property
Value
Parameters
2002h
Logic View toolbar
Data type
8 bit unsigned int
Measurement unit
--
Value
1 = comando di reset
Default value
0
Access
Read/Write
7.3 CHECKING THE RESULT OF A CONFIGURATION
When power is switched on or the module is reset, CANDPSX initializes with the last configuration
saved. To check the result of a configuration, read the parameter 2012h:
Property
Value
Parameter
2012h
Logic View manu
All parameters/System
Data type
16 bit unsigned int
Measurement unit
--
Value
0 = configuration OK
1 = invalid operating mode
2 = invalid CAN baud rate
