AXIS 233D - Troubleshooting
LED Indicator flash routine
* RFL (Resident Firmware Loader) check is a checksum method used to ensure that the software loading and
starting the firmware works correctly.
Case Color Description
Normal boot
sequence
Unlit Power on
RFL check*
Amber Kernel booting
System initiating
Green Shows steady green for 10 sec. for normal
operation after restart.
Unlit Steady connection/normal operation
Hard Factory
Default
Unlit Power on
RFL check*
Amber Steady - Kernel booting
Flashes - Firmware restore
Steady - System initiating
Green Shows steady green for 10 sec. for normal
operation after restart.
Unlit Steady connection/normal operation
Flash Upgrade Unlit Steady connection/normal operation
Amber Flashes - Firmware upgrade
Unlit Reset
RFL check*
Amber Steady - Kernel booting
Flashes - Firmware restore
Steady - System initiating
Green Shows steady green for 10 sec. for normal
operation after restart.
Unlit Steady connection/normal operation
No Network Unlit Power on
RFL check*
Amber Kernel booting
System initiating
Amber/red Flashes - No network
Green Network connected/normal operation
(10 sec.)
Unlit Steady connection/normal operation
AXIS DynDNS Unlit Steady connection/normal operation
Green Flashes- Dyn DNS connecting
Steady - DynDNS successful (10 sec.)
Red Steady - DynDNS failed (10 sec)
Unlit Steady connection/normal operation
Bad Checksum Red Flashes - RFL check* failed
