Axis 233D User Manual

66
AXIS 233D - Technical Specifications
Technical Specifications
Item Specification
Models • AXIS 233D Network Dome Camera 60 Hz
• AXIS 233D Network Dome Camera 50 Hz
Image sensor • 1/4” ExView HAD Progressive Scan CCD
Lens • F1.4 - 4.2
• F=3.4 - 119mm
• Automatic day/night IR filter
• Autofocus with 35x optical zoom
• Focus range: 100mm (wide) or 1000 mm (tele) to infinity
Angle of view
• Horizontal: 1.73 - 55.8
o
Zoom • 35x optical and 12x digital, Total 420x
Minimum illumination • Color: 0.5 lux at 30 IRE
• Black/white: 0.008 at 30 IRE
Range
• Pan: 360
o
continuous
• Tilt: 180
o
Speed Range
• Pan: 0.05 - 450
o
/sec
• Tilt: 0.05 - 450
o
/sec
Video compression • Motion-JPEG
• MPEG-4 Part2 (ISO/IEC 14496-2) with motion estimation
• Profiles: ASP level 0-5 and SP level 0-3
Resolutions • 4CIF, 2CIFExp, 2CIF, CIF, QCIF
• Maximum 704x480 (NTSC) 704x576 (PAL)
• Minimum 176x120 (NTSC) 176x144 (PAL)
• Horizontal resolution: 540 TVL
Frame rates (NTSC/PAL) • Up to 30/25 fps progressive scan video in all resolutions (Motion JPEG or MPEG-4)
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Wide Dynamic Range (WDR)
• Electronic image stabilization
• Automatic IR filter removal
• Compression levels: 100
• Manual shutter time settings
• Rotation: 0
o
, 180
o
• Aspect ratio correction
• Color and black/white
• Configurable Brightness and Sharpness
• Overlay capabilities: OSDI, preset ID, time, date, PTZ coordinates, text or image,
Privacy mask in 8 zones
Pan/Tilt/Zoom • E-flip
• 100 preset positions
• Guard tour
• Control queue
