67
AXIS 233D - Technical Specifications
Shutter time • 1.5s PAL(1/2s NTSC) - 1/30000s
Audio • Two-way (full or half Duplex) or one-way
• Audio compression: G.711 PCM 64kbit/s, G726 ADPCM 32 or 24 kbits
• Requires external microphone or line in.
• Mono audio output (line level) connects to PA system or active speaker with
built-in amplifier.
Security • Multiple user access levels with password protection
• IP address filtering
• HTTPS encryption
Users • 20 simultaneous viewers
• Unlimited number of users using MPEG-4 multicast
Alarm and event
management
• Events triggered by built-in motion detection, PTZ position, audio detection,
external inputs, temperature levels or according to schedule
• Image upload via FTP, e-mail and HTTP
• Event notification via TCP, e-mail, HTTP and external outputs
• Pre- and post-alarm buffer of 36 MB
Connectors • Ethernet 10BaseT/100BaseTX, RJ-45
• Three 8 pin connectors
4 alarm inputs 3.3 - 40VDC
4 relay outputs 50V 500 mA
Power in
Auxiliary power out 12VDC max 200mA
Audio line/Mic in
Audio line out
Casing • Metal/plastic casing
• Polycarbonate dome cover
Processors, memory and
clock
• CPU: AXIS ETRAX FS 32-bit RISC CPU
• Compression: AXIS ARTPEC-2 video compression chip + 8MB RAM
• RAM: 64MB
• Flash memory: 8 MB
• Battery backed up real-time clock
Power Power supply (indoor) included:
• 18-30 VAC, Max 25VA
• 22-40 VDC, Max 20W
Operating conditions
• Temperature: -5 - 50
o
C (23 - 122
o
F)
• Humidity: 20 - 80% RH (non-condensing)
Alarm when out of operating range.
Installation, management
and maintenance
• Configuration backup and restore
• AXIS Camera Station One for recording
• AXIS Camera Management on CD and web-based configuration
• Firmware upgrades over HTTP or FTP. Firmware available at www.axis.com
Video access from web
browser
• Camera live view for up to 20 clients
• Video recording to file (ASF)
• Sequence tour for up to 20 Axis video sources
• Customizable HTML pages.
