Axis A1001 Installation Guide

AXISA1001NetworkDoorController
PowersourceTotalmaximumloadonoutputs
PoweroverEthernetIEEE802.3af/802.3atType1Class3
7.5W
10–30VDC
14W
ThevoltageontheAxisproduct’spoweroutputsis12VDC(exceptfortheAuxiliaryConnector
whichhasavoltageof3.3VDC).Ifyourconnectingdevicehasamaximumampereratingoffor
example0.3A,thefollowingconversiongivesthepowerinwatts(W):
Power(W)=Voltage(V)xCurrent(I)
Power=12x0.3=3.6W
Thefollowingtableshowstheavailablepowerafterconnectionofthe0.3Adeviceintheexample.
PowersourceAvailablepower
PoweroverEthernetIEEE802.3af/802.3atType1Class3
7.5–3.6=3.9W
10–30VDC
14–3.6=10.4W
TheDCoutputonthefollowingconnectorsareconsideredaspoweroutputs:‘
•PowerLockConnector
•Power&RelayConnector
•ReaderI/OConnector
•AuxiliaryConnector
NO NO
NO
TICE TICE
TICE
Thepoweroutputoftheauxiliaryconnectorhasa3.3VDCvoltagerating.
Forconnectorspecications,seePowerConnectoronpage25andNetworkConnectoronpage26.
PerformanceLevelsforAccessControl
ThissectioncontainsperformancelevelinformationrequiredforUL294compliance.
FeatureLevel
DestructiveAttackTestI
LineSecurity
I
21
EN

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
