AXISA1601NetworkDoorController

Systemconﬁguration

Howtocreateanewhardwarecongurationwithoutperipherals

1.GotoSetup>HardwareCongurationandclickStartnewhardwareconguration.

2.EnteranamefortheAxisproduct.

3.SelectthenumberofconnecteddoorsandclickNext.

4.Congurethedoormonitors(doorpositionsensors)andlocksaccordingtoyourrequirementsandclickNext.Formore

informationabouttheavailableoptions,seeHowtoconguredoormonitorsandlocksonpage12.

5.CongurethereadersandREXdevicesthatwillbeusedandclickFinish.Formoreinformationabouttheavailableoptions,

seeHowtocongurereadersandREXdevicesonpage13.

6.ClickCloseorclickthelinktoviewthehardwarepinchart.

Howtoconguredoormonitorsandlocks

Whenyouhaveselectedadooroptioninthenewhardwareconguration,youcancongurethedoormonitorsandlocks.

1.Ifadoormonitorwillbeused,selectDoormonitorandthenselecttheoptionthatmatcheshowthedoormonitor

circuitswillbeconnected.

2.Ifthedoorlockshalllockimmediatelyafterthedoorhasbeenopened,selectCancelaccesstimeoncedoorisopened.

Ifyouwanttodelaytherelock,setthetimeofthedelayinmillisecondsinRelocktime.

3.Specifythedoormonitortimeoptionsor,ifnodoormonitorwillbeused,thelocktimeoptions.

4.Selecttheoptionsthatmatchhowthelockcircuitswillbeconnected.

5.Ifalockmonitorwillbeused,selectLockmonitorandthenselecttheoptionsthatmatchhowthelockmonitorcircuits

willbeconnected.

6.Iftheinputconnectionsfromreaders,REXdevices,anddoormonitorsshallbesupervised,selectEnablesupervisedinputs.

Formoreinformation,seeHowtousesupervisedinputsonpage14.

Note

•Mostlock,doormonitor,andreaderoptionscanbechangedwithoutresettingandstartinganewhardwareconguration.

GotoSetup>HardwareReconguration.

•Youcanconnectonelockmonitorperdoorcontroller.Soifyouusedouble-lockdoors,onlyoneofthelockscanhavealock

monitor.Iftwodoorsareconnectedtothesamedoorcontroller,lockmonitorscannotbeused.

Aboutdoormonitorandtimeoptions

Thefollowingdoormonitoroptionsareavailable:

•Doormonitor–Selectedbydefault.Eachdoorhasitsowndoormonitorthat,forexample,willsignalwhenthedoorhas

beenforcedopenoropentoolong.Deselectifnodoormonitorwillbeused.

-Opencircuit=Closeddoor–Selectifthedoormonitorcircuitisnormallyopen.Thedoormonitorgivesthedoor

opensignalwhenthecircuitisclosed.Thedoormonitorgivesthedoorclosedsignalwhenthecircuitisopen.

-Opencircuit=Opendoor–Selectifthedoormonitorcircuitisnormallyclosed.Thedoormonitorgivesthedoor

opensignalwhenthecircuitisopen.Thedoormonitorgivesthedoorclosedsignalwhenthecircuitisclosed.

•Cancelaccesstimeoncedoorisopened–Selecttopreventtailgating.Thelockwillbelockedassoonasthedoor

monitorindicatesthatthedoorhasbeenopened.

Thefollowingdoortimeoptionsarealwaysavailable:
