Axis P1344 User Manual

AXIS P1344 Network Camera
Accessing the product
Note
• The default administrator user name root is permanent and cannot be deleted.
• If the password for root is lost, the product must be reset to the factory default settings. See Reset to factory default
settings, on page 47.
The Live View page
If the Axis product has been customized to meet specific requireme nts, not all the items descr ibe d below will appear in the L ive View
page. The following provides an overview of ea ch availabl e button.
Controls on the Live View page
Click View size to scale the image down to 800 pixels wide or to full scale. Only available in MJPEG.
The Stream Profile drop-down list allows you to select a custom
ized or pre-programmed stream pro file. Stream
profiles are configured under Video & Audio > Stream Profiles.SeeStream Profiles, on page 19.
Click Pulse to activate the output for a defined period of time, such as s w itching on an external light for 20 seconds.
Click the Active/Inactive buttons to manually start and stop a connected device — e.g. switch an external light
on and off.
The Manual Trigger button can trigger an event directly from the Live View page. The button is configured under
Live View Config > Action Buttons.
11

Axis P1344 Specifications

General

Video Compression	H.264, Motion JPEG
Optical Zoom	No
Digital Zoom	Yes
Video Compression Formats	H.264, Motion JPEG
Frame Rate	30 fps
Image Formats Supported	JPEG
Ethernet LAN	Yes
Memory Card Slot(s)	No
Sensor Type	CMOS
Day/Night	Yes
Power Over Ethernet	Yes
Ingress Protection	IP66
Field of View	80°
Power	PoE
Network Interface	Ethernet
Camera Type	Fixed
Sensor Size	1/4"
Minimum Illumination	0.5 lux
White Balance	Auto, Manual
Signal-to-Noise Ratio (SNR)	50 dB
Supported Resolutions	640x480, 320x240
Streaming Capability	Multiple, individually configurable streams
Network Protocols Supported	IPv4/v6, HTTP, HTTPS, FTP, SMTP, Bonjour, UPnP, SNMP, DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Security Algorithms	HTTPS
Operating Temperature (T-T)	-10 °C to 50 °C
Aperture	F2.0
Operating Conditions	-10 °C to 50 °C
Storage Temperature	-20 °C to 60 °C
