Axis P1344 User Manual

AXIS P1344 Network Camera
Video and Audio
Video and Audio
The video and audio settings can be used to optimize video and audio quality. You can configure the following:
• Video stream settings. See page 18.
•Streamprofiles . See page 19.
• Camera settings. See page 20.
•Viewarea.Seepage 21.
• Overlay image. See page 21.
•Privacymask.Seepage 22.
•Focus.Seepage 22.
• Audio settings. See page 22.
• Audio clips. Se e page 24.
Video Stream
You can define the following video stream settings from Video & Audio > Video Stream:
•Image.Seepage 19.
• H.264. See page 19.
•MJPEG.Seepage 19.
Pixel Counter
The pixel counter shows the number of pixels in an area of the image. The pixel counter is useful in situations where there is a
requirement that the image is a certain size, for example in face recognition.
The pixel counter can be accessed from:
18

Axis P1344 Specifications

General

Video Compression	H.264, Motion JPEG
Optical Zoom	No
Digital Zoom	Yes
Video Compression Formats	H.264, Motion JPEG
Frame Rate	30 fps
Image Formats Supported	JPEG
Ethernet LAN	Yes
Memory Card Slot(s)	No
Sensor Type	CMOS
Day/Night	Yes
Power Over Ethernet	Yes
Ingress Protection	IP66
Field of View	80°
Power	PoE
Network Interface	Ethernet
Camera Type	Fixed
Sensor Size	1/4"
Minimum Illumination	0.5 lux
White Balance	Auto, Manual
Signal-to-Noise Ratio (SNR)	50 dB
Supported Resolutions	640x480, 320x240
Streaming Capability	Multiple, individually configurable streams
Network Protocols Supported	IPv4/v6, HTTP, HTTPS, FTP, SMTP, Bonjour, UPnP, SNMP, DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Security Algorithms	HTTPS
Operating Temperature (T-T)	-10 °C to 50 °C
Aperture	F2.0
Operating Conditions	-10 °C to 50 °C
Storage Temperature	-20 °C to 60 °C
