AXIS P1344 Network Camera
PTZ (Pan Tilt Zoom)
PTZ (Pan Tilt Zoom)
Preset Positi ons
A preset position is a predened view that can be used to quickly steer the camera to a specic location. Preset positions can
be accessed in several ways:
By selecting the preset from the Preset positions drop-down list in the Live View Page.
When setting up action rules. See page 33.
When setting up Guard Tour. See page 27.
To add a preset position:
1. Go to PTZ > Preset Positions.
2. Use the pan, tilt and zoom controls to steer the camera view to the desired position.
3. Enter a descriptive name in the Current position eld.
The product can be congured to return to the Home position when the PTZ functionality has been inactive for a specied length
of time. Enter the length of time in the eld and click Save. Set the time t o zero to prevent the product from autom atica lly
returning to the Home position.
To include the preset position name in the overlay text, go to Video & Audio,selectInclude overlay text and ente r the modier #P in
the eld. For more information about modiers, see File Naming & Date/Time Formats intheonlinehelp
.
Guard Tour
A guard tour displays the video s tream from different pre set positions, one-by-one, in a predetermined order or at random and for
cong
urable time periods. The enabled guard tour will keep running after the user has logged off or closed the browser.
T
o add a guard tour:
1. Go to PTZ>GuardTourand click Add.
2. Enter a descriptive name.
3. Specify the pause length between runs.
27
