AXIS P1344 Network Camera
Detectors
Set up motion detection
To set up a motion detection Include Window, follow these instructions :
1. Go to Detectors > Motion Detection.
2. Select the Configure Included Windows option and click New. Select t he new window in the list of window s and enter
adescriptivename.
3. Adjust the size (drag the bottom right-hand corner) and the positio n (click on the text at the top and drag to the desired
position) of the active w indow (window with red fr ame).
4. Adjust the Object Size, History and Sensitivity profile sliders (see Motion detection parameters for details). Any detected
motion within an active window is indicated by red peaks in the Activity window.
5. Click Save.
To exclude parts of the include window, select the Configure Excluded Windows and position the exclude window within the
include window.
To delete an include or exclude window, select the window in the list of
windows and click Del.
Motion detection parameters
The parameters controlling motion detection are described in the table below:
Parameter
Object Size
History
Sensitivity
Description
Object size relative to window
size.
Object memory length.
Difference in luminance
between background and
object.
High level (100%)
Only very large objects trigger
motion detection.
An object that appears in
the window triggers motion
detection for a l
ong time
before it is considered as
non-moving.
Ordinary colored objects on
ordinary backgrounds trigger
motion detection.
Medium l
evel (50%)
A large difference in luminance
is required to trigger motion
detection.
Low level (0%)
E
ven very small objects trigger
motion detection.
A
n object that appears in
the window triggers motion
detection only for a very short
time before it is considere d as
non-moving.
Only very bright objects on
a dark background trigger
motion detection.
30

Axis P1344 Specifications

General

Video Compression	H.264, Motion JPEG
Optical Zoom	No
Digital Zoom	Yes
Video Compression Formats	H.264, Motion JPEG
Frame Rate	30 fps
Image Formats Supported	JPEG
Ethernet LAN	Yes
Memory Card Slot(s)	No
Sensor Type	CMOS
Day/Night	Yes
Power Over Ethernet	Yes
Ingress Protection	IP66
Field of View	80°
Power	PoE
Network Interface	Ethernet
Camera Type	Fixed
Sensor Size	1/4"
Minimum Illumination	0.5 lux
White Balance	Auto, Manual
Signal-to-Noise Ratio (SNR)	50 dB
Supported Resolutions	640x480, 320x240
Streaming Capability	Multiple, individually configurable streams
Network Protocols Supported	IPv4/v6, HTTP, HTTPS, FTP, SMTP, Bonjour, UPnP, SNMP, DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Security Algorithms	HTTPS
Operating Temperature (T-T)	-10 °C to 50 °C
Aperture	F2.0
Operating Conditions	-10 °C to 50 °C
Storage Temperature	-20 °C to 60 °C
