Axis P1344 User Manual

AXIS P1344 Network Camera
Technical Specifications
Technical Specifications
Function/group
Item
Specifications
Model
AXIS P1344
Image sensor
Progressive scan RGB CMOS 1/4”
Lens
Varifocal f=3 – 8 mm, F1.2, DC-Iris, CS mount
Horizontal angle of view: 72° – 28°
Vertical angle of view: 44° – 18°
Diagonal angle of view: 84° – 32°
Day and night
functionality
Automatically removable infrared-cut filter
Minimum
illumination
Color: 0.3 lux, F1.2
B/W: 0.05 lux, F1.2
Camera
Shutter time
1/24500 s to 1/6 s
Video
compression
H.264 (MPEG-4 Part 10/AVC, Baseline profi le)
Motion JPEG
Resolutions
1440x900 (1.3 MP) scaled resolution available via VAPIX®
1280x800 (1 MP) to 160x90
Frame rate H.264 30 fps in all resolutions
Frame rate
Motion JPEG
30 fps in all resolutions
Video streaming
Multiple, individually configurable streams in H.264 and Motion JPEG
Controllable frame rate and bandwidth
VBR/CBR H.264
Pan/Tilt/Zoom
Digital PTZ, preset positions, guard tour
Video
Image settings
Compression, color, brightness, sharpness, contrast, white balance, exposure control,
exposure zones, backlight compensation, fine tuning of behavior at low light
Rotation: 0°, 90°, 180°, 270°
Mirroring of image s
Text and image overlay
Privacy mask
Corridor Format™
Wide dynamic range — dynamic contrast
Audio streaming Two-way, full duplex
Audio
compression
AACLC8kHz32kbit/s,16kHz64kbit/s
G.711 P
CM 8 kHz 64 kbit/s
G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s
Configurable bit rate
Audio input
3
.5 mm jack for mic/line in, max 80 mVpp for microphone/max 6.2 Vpp for line signal
Impedance: Min 1 kΩ, Mic-Power activated; Min 4 kΩ line
Tip: Signal/Bias
Ring: Bias
Sleeve: Ground
Power to external electret microphone: 1.3 V – 2.6 V (DC)
SNR: > 40dB
Audio output 3.5 mm jack for line out. max 2.8 Vpp
Impedance: max 100 Ω,normal<1Ω
SNR: > 40dB
Audio
54

Axis P1344 Specifications

General

Video Compression	H.264, Motion JPEG
Optical Zoom	No
Digital Zoom	Yes
Video Compression Formats	H.264, Motion JPEG
Frame Rate	30 fps
Image Formats Supported	JPEG
Ethernet LAN	Yes
Memory Card Slot(s)	No
Sensor Type	CMOS
Day/Night	Yes
Power Over Ethernet	Yes
Ingress Protection	IP66
Field of View	80°
Power	PoE
Network Interface	Ethernet
Camera Type	Fixed
Sensor Size	1/4"
Minimum Illumination	0.5 lux
White Balance	Auto, Manual
Signal-to-Noise Ratio (SNR)	50 dB
Supported Resolutions	640x480, 320x240
Streaming Capability	Multiple, individually configurable streams
Network Protocols Supported	IPv4/v6, HTTP, HTTPS, FTP, SMTP, Bonjour, UPnP, SNMP, DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Security Algorithms	HTTPS
Operating Temperature (T-T)	-10 °C to 50 °C
Aperture	F2.0
Operating Conditions	-10 °C to 50 °C
Storage Temperature	-20 °C to 60 °C
