Azbil Micro Flow CMS9500 - Page 31

23
Chapter 4. Operation
z
CMS0020/0050
Parameter Item Default setting Setting range
Condition for display (setting
in function setup mode)
P-0 1
Event output 1 (EV1)
0.0
0 to 999.9 (L/min)*
1
If
03
is set to
0 1
, or
02
.
00000000.
0 to 99999999 (L)
If
03
is set to
03
or
04
.
P-02
Event output 2 (EV2)
0.0
0 to 999.9 (L/min)*
1
If
04
is set to
0 1
, or
02
.
00000000.
0 to 99999999 (L)
If
04
is set to
03
or
04
.
P-03
EV1 hysteresis
5.0
*
2
0 to 10.0 (L/min)*
2
If
03
is set to
0 1
, or
02
.
P-04
EV2 hysteresis
5.0
*
2
0 to 10.0 (L/min)*
2
If
04
is set to
0 1
, or
02
.
P-05
EV1 on-delay
0
0 to 60 (s)
If
03
is set to
0 1
, or
02
.
P-06
EV2 on-delay
0
0 to 60 (s)
If
04
is set to
0 1
, or
02
.
P-07
Initial reverse-totalized ow
00000000.
0 to 99999999 (L)
If
02
is set to
02
.
P-08
Gas type conversion factor
1.000
0.100 to 8.000
If
08
is set to
08
.
P-0G
Analog output scaling
100
10 to 250 (%)
If
0G
is set to
04
.
z
CMS0200/0500
Parameter Item Default setting Setting range
Condition for display (setting
in function setup mode)
P-0 1
Event output 1 (EV1)
0.
0 to 9999 (L/min)*
1
If
03
is set to
0 1
, or
02
.
00000000.
0 to 99999999 (× 10L)
If
03
is set to
03
or
04
.
P-02
Event output 2 (EV2)
0.
0 to 9999 (L/min)*
1
If
04
is set to
0 1
, or
02
.
00000000.
0 to 99999999 (× 10L)
If
04
is set to
03
or
04
.
P-03
EV1 hysteresis
50.
*
2
0 to 100 (L/min)*
2
If
03
is set to
0 1
, or
02
.
P-04
EV2 hysteresis
50.
*
2
0 to 100 (L/min)*
2
If
04
is set to
0 1
, or
02
.
P-05
EV1 on-delay
0
0 to 60 (s)
If
03
is set to
0 1
, or
02
.
P-06
EV2 on-delay
0
0 to 60 (s)
If
04
is set to
0 1
, or
02
.
P-07
Initial reverse-totalized ow
00000000.
0 to 99999999 (× 10L)
If
02
is set to
02
.
P-08
Gas type conversion factor
1.000
0.100 to 8.000
If
08
is set to
08
.
P-0G
Analog output scaling
100
10 to 250 (%)
If
0G
is set to
04
.
*1. If a user-specied gas type is selected in function setup
08
, and if the gas type conversion factor (
P-
08
) is set between 0.100 and 0.499, the setting ranges are as follows.
CMS0002: 0.000 to 0.995 (in 0.005 increments)
CMS0020: 0.00 to 9.95 (in 0.05 increments)
CMS0200: 0.0 to 99.5 (in 0.5 increments)
*2. If a user-specied gas type is selected in function setup
08
, and if the gas type conversion factor (
P-
08
) is set between 0.100 and 0.499, the setting ranges are as follows.
Default setting Setting range
CMS0002: 0.05, 0.000 to 0.100 (in 0.005 increments)
CMS0020: 0.5, 0.00 to 1.00 (in 0.05 increments)
CMS0200: 5.0, 0.0 to 10.0 (in 0.5 increments)
Handling Precautions
• Event output settings should be set within the measurement range.
