Chapter 3. MOUNTING AND WIRING
z
External dimensions
unit : mm
48
L
OK
SP1 SP2 SP3 EV1 EV2
ENT
DISP
PV
SP
48
Mounting bracket (accessory)
Applicable panel plate
thickness is 2 to 7 mm
9
2 61 12.7
44.8
3.5
44.8
10
9.512
13.5 10
2-Rc1/8
2-HEX14
No.9
No.1
Connection
port IN
Connection
port OUT
Connector (accessory)
Loader
jack
z
Panel cutout
unit : mm
20 min.
20 min.
0
+0.5
45
0
+0.5
(48 X N -3)
0
+0.5
45
(N: Number of mounted units)
(48 X N -3)
0
+0.5
0
+0.5
45
0
+0.5
45
Vertical gang-mounting
Horizontal gang-mounting
Individual mounting
