Azbil MPC0002 - Chapter 7: Specifications (Continued) (Page 41); MPC0005 and MPC0020 Specifications

7-3
Chapter 7. SPECIFICATIONS
MPC0005 MPC0020
Proportional solenoid valve
Normally closed when de-energized (N.C.)
5.00 L/min (standard) 20.0 L/min (standard)
Air/Nitrogen, argon, carbon dioxide (CO
2
)
Note; The gas must be a dry gas not containing corrosive
components (chlorine, sulfur, acid).
The gas must also be a clean gas not containing dust or oil mist.
2 to 100 % FS *
1
Within 1.0 s (typ) to set point ±2 % FS
±2 % FS max. (at standard temperature and differential pressure)
±1 % FS max.
A maximum of 0.1 % FS per °C
0.2 % FS max. 0.2 % FS max.
0.3 % FS max. 0.2 % FS max.
0.5 % FS max. 0.2 % FS max.
0.2 MPa [290 PSI] (Inlet pressure: 0.2 MPa [290 PSI] (gauge),
outlet pressure: 0.0 MPa [0PSI] (gauge))
0.1 MPa [145 PSI] 0.15 MPa [217.5 PSI]
0.3 MPa [435 PSI] max. 0.05 to 0.3 MPa [72.5 to 435 PSI]
0.5 MPa [725PSI] (gauge)
-10 to +50 °C [14 to 122 °F]
(0 to 50 °C [32 to 122 °F] when RS-485 communication)
-10 to +60 °C [14 to 140 °F]
10 to 90 %RH (no condensation allowed)
(1)Key operation (2)External setup voltage input (only for the model
with analog I/O function) (3)Loader communication *
5
(4)RS-485
communications (only for the model RS-485 communications function)
*
6
*1
0 to 5 V DC/1 to 5 V DC (selectable by function setup), Input
impedance : 1 MΩ ±10 % (only for the model with analog I/O function)
7-segment LED 8 digits
(For the instantaneous flowrate display: 4 digits and for the
setting flowrate display: 4 digits)
*
1
±2 % FS ±1 digit
(at standard temperature and differential pressure)
0.0 to 9,999,999.9 L 0 to 99,999,999 L
0.1 L 1 L
(1)At each 50 L count (1)At each 200 L count
(2)At each after 1 hour from the previous backup
0 to full-scale flowrate (scaling available)
0 to 5 V DC/1 to 5 V DC
(selectable by function setup)
