Azbil VDC User Manual

Model MTG11A/18A/11B/18B/14C System configuration and structure Azbil Corporation
1-6 Model MTG11A/18A, MTG11B/18B, MTG14C
System configuration for analog output and contact output
System configuration
In the system configuration shown below, the instantaneous flow rate is output as 4-20
mA analog signal and alarm is output when the status output is configured for the
alarm function. As an alarm, self diagnosis output (critical failure) or upper/lower
limit alarm is output.
• Two wired magnetic flowmeter: Measures flow rate and outputs the instantaneous
flow rate value as an analog signal.
• Communicator: Used to communicate with this instrument, read data and change
the instrument data settings.
• Pulse output receiver equipment: It receiver the pulse output, and displays the
totalized value.
~Note Open collector: pulse output method using the transistor contact.
Figure 1-4-1 System configuration for analog output 1 (Integral type)
Figure 1-4-2 System configuration for analog output 2 (Remote type)
Communicator
+
+
SFC / HART Communicator
4-20 mA
Analog signal
250Ω
resistance
Power supply
24V DC
Host
control
system
+
++
Pulse output
receiving function
Pulse output
Grounding *
-
-
---
Signal receiver
(open collector)
Two wired
magnetic flowmeter
*: The most effective grounding
method is direct connection to
earth ground with minimal
impedance.
Communicator
SFC / HART Communicator
4-20 mA
Analog signal
250Ω
resistance
Power supply
24V DC
Host
control
system
(1-5V
input)
+
+
+
+
Pulse output
Pulse output
receiving function
Grounding *
-
-
-
-
Signal receiver
(open collector)
Two wired magnetic flowmeter
(Remote type)
*: The most effective grounding
method is direct connection to
earth ground with minimal
impedance.
Grounding *
CM2-MTG300-2001.book 6 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
