Azbil Corporation Model MTG11A/18A/11B/18B/14C System configuration and structure
Model MTG11A/18A, MTG11B/18B, MTG14C 1-13
Indicator/data setting device
Description
The indicator/data setting device has the following function and structure.
Displays the instantaneous flow rate value and internal conditions of the
instrument.
The indicator face can be turned at intervals of 90 degrees through one turn.
Refer to “ Changing the direction of display/data setting device” on page 2-8.
Names of various parts
The names of various parts of the indicator/data setting device are shown.
Figure 1-9 Indicator/data setting device details
Figure 1-10 Display
Liquid crystal display
Setscrew
Meter cover
U
p
t
o
a
n
t
i
-
c
l
o
c
k
w
i
s
e
9
0
U
p
t
o
c
l
o
c
k
w
i
s
e
9
0
Mode key
Right shift key
Decrement key
Increment key
Hole when it rotates 90
Fixed screw
three places
