Azbil VDC User Manual

Instrument installation Azbil Corporation
2-6 Model MTG11A/18A, MTG11B/18B, MTG14C
Method of changing the direction of converter
In some location, the direction of the converter may be unsuitable if the detector is
installed as it was shipped. In this case, the converter can be repositioned before
installation.
The direction of the detector and the converter (integral type) can be changed using the
procedure described below.
Figure 2-4 Change the direction of converter
90 Clockwise
90 Anti-clockwise
180 Reversing
U
p
t
o
a
n
t
i
-
c
l
o
c
k
w
i
s
e
1
8
0
U
p
t
o
c
l
o
c
k
w
i
s
e
1
8
0
CM2-MTG300-2001.book 6 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
