Azbil Corporation Instrument installation
Model MTG11A/18A, MTG11B/18B, MTG14C 2-7
~Note • Disconnect all cables before proceeding to change the orientation of
the detector and the converter.
• Do not perform the orientation change in locations containing
humidity and dust.
• During reassembly check the sealing surface and the condition of the
O-ring for any damage.
Step Procedure
1 Turn off the power supply (with a breaker etc.) of the converter.
2 Using an M5 wrench remove the four screws securing the converter to
the detector.
~Note After removing the screws and when changing the orientation
of the detector and the converter. Ensure caution not to apply
any force or load to the cable and the connectors. Failure to do
so might cause damage to the cable, connector, printed circuit
board or cause open circuit and malfunctions.
3 Decides the direction between the detector and the converter.
~Note Do not twist the cable when the connected cable between the
detector and the converter rotate. Damage might cause
connector and it cause the open circuit etc. of wiring.
4 Tightens the four set screw (The tightening torque: 4.4 N•m ±15%). It
tighten four screws in the diagonal, and four screws must tighten almost
evenly. Moreover, note that there is possibility to bites the dust into the
tapped hole after tightening work in the place with dust.
CM2-MTG300-2001.book 7 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
To Next Page
