Commission the System | 43
each of these categories a display can be set to receive data from sources as part of the
Default group or receive the source data independently from the group (None)
The example below shows the available options for position sources, and that the GS15
GPS is used by all displays with group selection set to B&G. If you selected the GS10 all
displays in the Default group would use the input to the Zeus 12 Device.
Group Source Selection (NONE)
You may prefer one display to receive its position information from the GS10 antenna
independently from the rest of the displays in the default source selection group.
Set the position information to None.
Under the position category,
change group selection from
Default to None
PLOT
MARK
GOTO
VESSEL
Select None
PLOT
MARK
GOTO
VESSEL
PLOT
MARK
GOTO
VESSEL
Select the Z12 H3000
MENU
9
WIN
to exit
Source Selection Advanced
Allows the selection of a source not using Default group - eg Engine and Tank sources.
