Specifi cations | 59
Display Specifi c Specifi cations
Z8 Z12
Display size 8 “ Diagonal Display size 12.1” Diagonal
Display resolution 800 x 600 Display resolution 1024 x 768
Brightness (max) 1500 nits Brightness 1500
Contrast ratio 850:1 Contrast ratio 600:1
Viewing angle 60 deg. above and below normal axis with: >75% nominal
brightness >100:1 contrast ratio
60 deg. side to side about normal axis with: >75% nominal
brightness >100:1 contrast ratio
Height 212 mm (8.35") Height 266 mm (10.47”)
Width 285 mm (11.22") Width 356 mm (14.01”)
Depth 111 mm (4.38") Depth 122.7 mm (4.83”)
Weight 3.2 kg (7 lb) Weight 5.5 kg (11.5 lb)
Current Draw (in
Watts) at 12/24VDC
Display only
21.6W or 1.8A @
12.0 V DC / 21.6W or
0.9A @ 24VDC
Current Draw (in
Watts) at 12/24 VDC
Display only
33.6W or 2.8A
@ 12.0 V DC /
33.6W or 1.4A @
24VDC
Supported NMEA0183 Sentences
TX / RX GPS
Receive GGA GLL GSA GSV VTG ZDA
Transmit GGA GLL GSA GSV VTG ZDA
Navigation
Receive RMC
Transmit AAM APB BOD BWC BWR RMC RMB XTE
Echo
Receive DBT DPT MTW VLW VHW
Transmit DBT DPT MTW VLW VHW
Compass
Receive HDG HDT HDM
Transmit HDG
Wind
Receive MWV MWD
Transmit MWV
AIS / DSC
Receive DSC DSE VDM AIS sentences are not bridged to or from
SimNet.
MARPA
Transmit TLL TTM These are only out put sentences
Supported baud rates 4,800, 9,600, 19,200, 38,400 Note. Port will transmit and
receive at the set baud rate
Ethernet 10/100 base Ethernet, three ports
Max number of dis-
plays
6 in any combination Z8 or Z12
External connectors
(front)
x 1 USB and x 1 SD
External Connectors
(rear)
Power (power control, ext. alarm), Video-in (NMEA 0183/
Composite video x2), SimNet (NMEA2000), Network (3 x eth-
ernet, USB x 1, Video Out (DVI-I x 1)
