58 | Specifi cations
Specifi cations 12.
Mechanical
Back Case Die cast aluminium
Heat Sinking Direct heat transfer from processor to casting
Screen Direct bonded, anti refl ective, LED backlit
Environmental
Operating tempera-
ture
-15° C to +55° C (+5° F to +131° F)
Waterproof integrity IPx7
Certifi cates of
Conformity
CE(EN60945:2002)/CTick
Electrical
Operating Voltage 12 or 24 V DC (9 - 34 V DC max)
Processor Via Eden ULV 1.6 GHz
RAM 512 MB
Hard drive 80 GB
User Interface
User interface Direct access keys (DAK’s), alphanumeric keypad, rotary knob
with push-to-Enter
Languages (31) English (UK), English (US), German, French, Spanish,
Italian, Portuguese, Croatian, Finnish, Icelandic, Dutch,
Norwegian, Polish, Swedish, Slovenian, Russian, Ukrainian,
Bulgarian, Asian language pack
Plotter Characteristics
Display modes Head-up*, Course-up, North-up (*external heading or COG)
Cartography Embedded: Navico Insight HD (US) Navionics (Rest of World)
Navionics Platinum Plus via SD Card
Latitude Limit 83º North, 85º South
Alarms Position, Off-Course, Waypoint Radius, Arrival, Anchor, Anchor
Depth, Shallow, Deep, Water Temp Rate, Low
Boat Speed, True Wind Shift, True Wind High, True Wind Low,
Guard Zone 1 & 2, Voltage Hi/Lo,
Missing Data: Depth/Rudder/Wind/Heading/Weather,
Weather: Lightning, Severe Weather, Storm, Weather
Watchbox,
Vessels: Dangerous, AIS Lost, Message, MARPA Lost, MARPA
Unavailable, Autopilot Alarms
Radar Characteristics
Radar compatibility Broadband: B&G BroadBand™ Radar
Simrad HD Digital Series 2 kW to 25 kW
Display Modes Head-up, Course-up*, North-up*, Relative Motion (*Heading
input required)
Echo Trails Intervals: 15 sec, 30 sec, 1 min, 3 min, Continuous. Clear
Trails
VRM/EBL 2: User confi gurable
Video In
Channels Two multiplexed
Format Composite
Standard Support for NTSC type N and 4.4.43, PAL type B, D,G,H, I,
M,N, Selected by user
Comms
NMEA0183 1 x RS422 port
