Bacharach HI FLOW Sampler User Manual

Hi Flow Sampler Operation
Instruction 0055-9017
19
3.13 Menu Mode – Basic or Expanded
Selecting Menu Mode from the Menu System allows the user to select
whether only the most basic amount of information is displayed on the
Main Screen (Basic Menu mode), or if all available information is
displayed (Expanded Menu mode).
Refer to Section 3.8 Selecting the Basic or Expanded Menu Mode for
detailed information on how to select the desired menu mode, and learn
about what type of information is displayed in each mode.
3.14 Operating Mode – Automatic or Manual
Note: The Operating Mode can only be selected if operating in the Expanded
Menu Mode. Refer to Section 3.8.
Selecting Operating Mode from the Expanded Menu System allows the
user to set the instrument’s operating mode to either Automatic or
Manual.
3.14.1 Automatic 2-Stage Measurement Mode
In the Automatic 2-Stage Mode the unit performs a leak rate
measurement at first a high flow rate for 1 minute, and then
automatically shifts to a lower flow rate and performs another
measurement for another minute. The final measured and calculated
values are automatically saved in memory. This mode is used to measure
leaks that are easily identifiable and captured.
Select the automatic measurement mode as follows:
1. From the Expanded Main Screen, select Menu > Operating Mode.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
C a l i b r a t i o n
S e t F l o w U n i t s
M e n u M o d e
O p e r a t i n g M o d e
A c c e s s R e c o r d s
[ 0 0 0 1 ] ( M ) S - -
2. Highlight Automatic 2-Stage, and then press the I/O key.
0 2 / 2 1 / 0 3 0 9 : 4 5 : 3 0
A u t o m a t i c 2 - S t a g e
M a n u a l 2 - S t a g e
M a n u a l 1 - S t a g e
[ 0 0 0 5 ] ( M ) S - -
3. Press ESC to return to the Main Screen. Observe that (A) should
appear at the bottom of the screen
