Bacharach HI FLOW Sampler User Manual

Operation Hi Flow Sampler
Instruction 0055-9017
24
3.15.2 View Records
View the records stored in memory on the unit’s LCD screen as follows:
1. Access the Review Record Screen from the Expanded Main Screen by
selecting Menu > Access Records > View Records. This screen
allows the user to view a short summary of each record stored in
memory. If no records are in memory, then the message “No Records
Saved” briefly appears in the message line.
The first two lines in this screen contain the Test ID information as
entered per Section 3.17 Access Test IDs.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
T e s t I D L i n e 1
T e s t I D L i n e 2
L e a k ( l p m ) x . x x
# 1 - # 2 ( % ) y y . y
[ 0 0 0 1 ] ( M )
S - -
Where: x.xx is the recorded leak rate in ether lpm or cfm
yy.y is the percent difference between measurements #1 and
#2
2. Use the  keys to scroll through the saved records.
3. Press ESC three times to return to the Main Screen.
3.15.3 Erase Records
Erase all records from memory as follows:
1. From the Expanded Main Screen, select Menu > Access Records >
Erase Records.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
S e n d R e c o r d s
V i e w R e c o r d s
E r a s e R e c o r d s
[ 0 0 0 1 ] ( M )
S - -
2. Confirm or cancel the erase process by selecting Yes or No.
0 2 / 2 1 / 0 3 0 9 : 4 5 : 3 0
E r a s e a l l r e c o r d s ?
Y e s
N o
[ 0 0 0 1 ] ( A )
S - -
3. Observe the message “Erasing all records” appears at the bottom of
the display during the erase process.
