Bacharach HI FLOW Sampler User Manual

Operation Hi Flow Sampler
Instruction 0055-9017
28
3. Select the displayed Test ID by pressing the I/Okey, and then
return to the Main Screen by pressing ESC twice. Observe that [0005]
is now displayed at the bottom of the screen.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
L e a k ( N o t A v a i l . )
S p e e d ( L O < > H I )
S a v e
S t a r t
M e n u
[ 0 0 0 5 ] ( A ) S - -
3.17.2 Edit Test IDs
Edit a previously entered Test ID or to create a new one as follows:
1. First select the Test ID to edit per Section 3.17.1 Select Test IDs. To
create a new Test ID, select the last Test ID number that can be
displayed – the last Test ID number will always be blank.
2. From the Expanded Main Screen, select Menu > Access Test IDs >
Edit Test IDs.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
S e l e c t T e s t I D s
E d i t T e s t I D s
S e n d T e s t I D s
E r a s e T e s t I D s
[ 0 0 0 5 ] ( A ) S - -
3. Use the following keys to select and then enter the desired character.
 – displays desired alphanumerical character
I/O – selects displayed character and moves cursor one space
to the right
ESC – moves cursor one space to the left
Tip: To quickly scroll through the characters, press and hold down
the  or  key.
Tip: The “space” character is between the number “9” and the capital
“A”.
In the example below, the Test Location has been changed from 1 to
2 with the cursor positioned to the immediate right of the number 2.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
T e s t L o c a t i o n 2 |
O p e r a t o r J o h n D o e
[ 0 0 0 5 ] ( A ) S - -
4. After all characters have been selected, press and hold down the
I/Okey to move the cursor to the end of the screen; after which, the
screen shown in Step 2 should reappear.
